Garmin Astro T5 Extra Collar

IMPORTANT NOTICE - Due to circumstances outside of our control and restrictions in place by Garmin we are unable to ship any Garmin GPS related products outside the United States until further notice. We apologize for the inconvenience.

This collar is a dog TRACKING ONLY unit for use with the Garmin Alpha 200i, Garmin Alpha 100, Garmin Astro 320, Garmin PRO 550 PLUS, and Garmin Astro 430 handheld devices. Now there is finally an option that allows you to use your Alpha system in field trial events! The T5 features the new GLONASS-enabled receivers that are capable of more accurate detection with higher sensitivity. The collar has remote controlled LED beacon lights. The Garmin Astro T5 Extra Collar Units Come With A Blue Collar Strap! This collar is rugged and water rated up to 32 feet.

Garmin T5 Tracking Collar Features:

T5 Collar can be configured to work with either the Garmin Astro 320, Garmin Astro 430, Garmin PRO 550 Plus, or the Garmin Alpha.
Top-mounted, high sensitivity, GLONASS-enabled satellite receiver.
22.5” braided-steel antenna, with 18.5” antenna available as an option.
User-configurable Rescue Mode to extend battery life.
Updates dog positions every 5, 10, 30, or 120 seconds.
Easy-to-replace 27”x1” collar strap (no tools needed).
Extreme waterproofing (up to 10 meters, or ~33 feet).
Rechargeable, replaceable Lithium Ion Battery.

Rescue Mode:

With rescue mode on, the T5 has around a 30 hour battery life.
5 second update rate means around 13 hours (before battery reaches 25%).
When battery reaches 25%, rescue mode changes the update rate to 2 minutes.
2 minute update rate means about 16 additional hours.
Total: approximately 30 hours.

Physical and Performance

Unit dimensions (WxHxD): 3.5" x 1.75” x 1.85" (8.9 x 4.4 x 4.7 cm)
Weight: 6.6 oz (188.0 g) for transmitter and antenna; 9.3 oz (265.0 g) total weight
Battery life: 20-40 hours
Battery type: rechargeable lithium-ion pack; user replaceable
Interface: USB
Water Rating: 1 ATM (10 meters)
High-sensitivity GPS/GLONASS receiver: Yes
GPS antenna: top, orange
Stimulation/Vibration/Tone: No
LED beacon lights: Yes
Frequency band: MURS (The T 5 and TT™ 15 are only compatible with the Astro® 320 and the Alpha™ 100. The T5 and TT15 can be configured for operation with either handheld but cannot be tracked simultaneously by both the Astro 320 and the Alpha 100)
Rescue mode: Yes
Replaceable collar straps: Yes
Collar compatibility: 1” (2.54 cm)

In The Box

T 5 dog device with rechargeable lithium-ion battery
1-inch blue collar strap
Charging clip
AC adapter
Vehicle power cable
Manual

FAQ

Can I pair this collar with my Garmin Alpha?

Yes. You can pair this collar with your Garmin Alpha or Garmin Astro. When paired up with the Alpha 100 or Alpha 200i, you only use the tracking features of the collar.

Can this collar be tracked with my an Garmin Alpha and Garmin Astro simultaneously?

The T5 collar can be tracked by the Alpha 100, Alpha 200i, and Astro 430 handhelds simultaneously, but if the collar is paired with the Astro 320 only the Astro 320 handhelds can track the collar.

Can the collar strap be changed to a different color?

Yes. We can change the blue color strap to one of our available colors.
